Product Introduction

TSM series temperature shock test chamber can provide high temperature and low temperature test spaces, the test piece is transferred in the two spaces through the basket, to achieve the thermal shock test of rapid temperature change between the upper and lower limit temperatures.

Parameter Table
Model 401FL 501SL 601SL 402SL 502SL 602SL 403SL 503SL 603SL 405SL 505SL 605SL 410SW 510SW 610SW 420SW 520SW
Volume L 125 125 125 250 250 250 358 358 358 486 486 486 1243 1243 1243 2184 2184
Basket Depth mm 300 300 300 400 400 400 500 500 500 650 650 650 800 800 800 1000 1000
Basket Width mm 300 300 300 400 400 400 500 500 500 650 650 650 800 800 800 1000 1000
Basket Height mm 300 300 300 400 400 400 500 500 500 500 500 500 800 800 800 1000 1000
Inner Depth mm 500 500 500 605 605 605 705 705 705 850 850 850 1000 1000 1000 1200 1200
Inner Width mm 500 500 500 700 700 700 800 800 800 900 900 900 1130 1130 1130 1300 1300
Inner Height mm 500 500 500 590 590 750 635 635 635 650 650 750 1100 1100 1100 1400 1400
Outer Deepth mm 2200 1950 2110 1810 1810 2330 1910 1910 1910 2050 2050 2550 1810 1810 1810 2150 2150
Outer Width mm 1180 1180 1180 1390 1390 1460 1490 1490 1490 1590 1590 1620 3360 3360 3360 4500 4500
Outer Height mm 1790 1790 2100 1850 1850 2220 2100 2100 2100 2030 2030 2380 2290 2290 2290 2050 2050
Chamber Structure Vertical Horizontal
Temperature Performance Parameters
Temperature Range (High Temperature Chamber) ℃ RT+25~180
Temperature Range (Low Temperature Chamber) ℃ -70~-10
Impact Temperature (High Temperature) ℃ 150
Impact Temperature (Low Temperature) ℃ -40 -50 -60 -40 -50 -60 -40 -50 -60 -40 -50 -60 -40 -50 -60 -40 -50
Conversion Time s 15
Revocery Time min 5
Heating Time (High Temperature Chamber) min RT→180℃≤60min
Cooling Time (Low Temperature Chamber) min RT→-65℃≤60min
Load (Aluminum ingots) kg 5 10 15 20 40 60
Temperature Fluctuations ℃ ≤1
Temperature Uniformity ℃ ≤2
Temperature Deviation ℃ ±2
Power Suppply AC380V 50Hz TN-S
Power kW 18 18 21 21 24 26 24 30 44 30 44 55 45 67 76 67 79
Noise dB(A) 70 70 72 70 72 75 72 72 75 72 75 75 75 75 78 75 78
Cooling Method Air-cooled Water-cooled
Total Weight kg 800 850 920 900 950 1100 1100 1160 1280 1200 1350 1500 1300 1450 1620 1700 1900
