Rapid Temperature Change Test Chamber

Email: shanyf@chinasti.com

Tel: 008616651737187

Whatsapp: 8616651737187

Rapid Temperature Change Test Chamber

Rapid Temperature Change Test Chamber - SDE Series.pdf

description1

Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Product Introduction

Rapid temperature change test chamber can provide high temperature, low temperature, humidity and other environmental simulation conditions, used in aviation, aerospace, automobile, shipbuilding, military, electronics, petrochemical and other fields of environmental test or reliability test: high and low temperature storage test, high and low temperature cycle test, constant humidity heat test, alternating humidity heat test, etc.

Parameter Table

Model	S/SH	702A	702B	702C	702D	705A	705B	705C	705D	705E	710A	710B	710C	710D	710E	710F	710G	710H
Volume	L	210				504					1000
Inner Depth	mm	500				700					1000
Inner Width	mm	600				800					1000
Inner Height	mm	700				900					1000
Outer Depth	mm	1850	2330			2440		2570			2740	2910	3100
Outer Width	mm	800				1000					1200
Outer Height	mm	1730				1930					2050
Temperature Performance Parameters
Temperature Range	℃	-70~+150
Temperature Change Rate Range	℃	-55~+85
Average Temperature Change Rate	℃/min	5	5	10	15	5	5	10	15	15	5	5	10	10	10	15	15	15
Temperature Change Linear Rate	℃/min	3	3	5	10	3	3	5	10	10	3	3	5	5	5	10	10	10
Load (Aluminum ingots)	kg	20	40	20	20	20	40	40	20	50	20	50	40	80	120	50	80	120
Temperature Fluctuations	℃	≤1
Temperature Uniformity	℃	≤2
Temperature Deviation	℃	±2
Heating Power	kW	5	7.5	12	15	7.5	12	15	21	24	12	15	21	27	30	36	45	54
Temperature and Humidity Climate Parameters
Teamperature Range	℃	20-85
Humidity Range	%RH	20-98
Temperature Fluctuations	℃	≤1
Temperature Uniformity	℃	≤1
Temperature Deviation	℃	±2
Humidity Deviation	%RH	+2/-3%RH(Humidity>75%RH), ±5%RH(Humidity≤75%RH)
Humidification Power	kW	3				4.5
Power Supply		AC380V 50Hz TN-S
Power	S(kW)	12.5	18	32	38	18	27.5	38	50	60.5	27.5	38	50	66.5	74	90	118	128
Power	SH(kW)	15.5	21	35	41	22.5	32	42.5	54.5	65	32	42..5	54.5	71	78.5	94.5	122.5	132.5
Noise	dB(A)	72							75		72		75			78
Cooling Method	Water-cooled
Total Weight	kg	380	400	500	600	1100	1200	1350	1600	1700	1600	1700	1750	1800	1885	1900	2100	2300
